S61400

The Danaher Motion SERVOSTAR S61400 is a high-performance digital servo amplifier belonging to the SERVOSTAR 600 family, specifically known as the SERVOSTAR 614. Rated at 14 Amps RMS continuous output current and designed to operate across a wide input voltage range of 230–480 VAC at 50 Hz or 208–480 VAC at 60 Hz, this drive is engineered for demanding single-axis motion control applications in industrial machinery, CNC machine tools, robotics, and automated manufacturing systems. Its broad voltage compatibility makes it well-suited for both North American and international installations without requiring step-down transformers or other power conditioning equipment.

This drive fits directly into any system originally designed around the SERVOSTAR 600 series platform. It supports a rich set of motor feedback options including resolver and high-resolution sin/cos encoder, and the platform is compatible with multiple fieldbus expansion options such as DeviceNet, PROFIBUS, SERCOS, EtherCAT, and SynqNet — making it easy to integrate into virtually any PLC or motion controller environment. The unit also includes an internal regen resistor as standard, with provisions for external resistors if the application demands higher energy absorption. A 24 VDC auxiliary supply powers the control logic independently, preserving safe operation and communication even when the main power stage is disabled.S61400

This specific unit is offered in used and fully tested condition, giving buyers a reliable, cost-effective path to sourcing a discontinued part without the long lead times associated with new-old-stock alternatives. Each unit is verified for proper electrical operation prior to shipment, providing confidence that the drive will perform to its original specifications once installed. The 100 mm instrument width of the 614-rated model is a key dimensional detail when planning panel layouts or replacing a unit in an existing enclosure.S61400

Whether you are maintaining legacy automation equipment, rebuilding a CNC axis, or seeking a proven servo drive at reduced cost, this pre-owned unit offers a practical solution. The SERVOSTAR 600 series was widely deployed across industries worldwide, meaning replacement parts, documentation, and setup software remain accessible. Purchasing a used and tested unit from an established supplier helps minimize downtime and keeps aging but productive machinery running at full capacity.S61400

Rated Output Current: Delivers 14 Amps RMS continuous output current per phase, suitable for mid-range servo motor applications.
Wide Input Voltage: Accepts 230–480 VAC at 50 Hz or 208–480 VAC at 60 Hz, enabling worldwide installation compatibility.
Feedback Support: Compatible with resolver and high-resolution sin/cos encoder feedback for precise closed-loop motion control.
Fieldbus Expansion: Supports optional expansion cards for DeviceNet, PROFIBUS, SERCOS, EtherCAT, and SynqNet communication protocols.
Used & Tested: This unit has been fully tested to verify electrical functionality, offering a cost-effective alternative to new or new-old-stock inventory.
